Practical and Fast
The RS-III-PRO can instantly respond to all your needs and all other features that instantly give you information you need while driving.
Simple and Elegant
You will be fascinated with the RS-III-PRO model at first look. Get ready for journeys that you would’nt want to end with the RS-III-PRO, which achieves perfection with simple and modern touches in addition to the classic bicycle design.
Quality Equipment
The RS-III-PRO model is equipped with best in class features and materials , both in terms of performance and quality.
A Whole with Its Features
Performance, high-quality materials, instrument panels, features and lighting power all match the RS-III-PRO; offers lipsticks full of passion.
TECHNICIAL SPECIFICATIONS
-
- Motor
36V 250W
- Battery
36V 10Ah
- Top Speed
25 km/h
- Range
45-60 km.
- Charging Time
4 – 6 Hours
- Wheel
20” Alloy
- Crank Set
Prowheel PRO 546PP Alloy
- Shifter Right
Shimano TX50 7SP
- Rim
Alloy Double Wall 20”
- Front / Rear Tire
CST
- Front / Rear Brake
YX-DB06 Alloy Disc / Disc
- Display
LCD Display
- Saddle
Gel Comfortable Sport
- Freewheel
Shimano MF-TZ500 7SP
- Chain
KMC 27
- Fender
Plastic
- Front Fork
Suspension Fork Alloy Crown (Locked-Out)
- Front / Rear Light
36V Controled By Display / Plastic LED
- Electronic Cable
Waterproof Harness
- Rear Derailleur
Shimano RD-TY300D 7SP
- Net / Max. Weight
24 kg. / 135 kg.
*Range Of The E-Bike Depends Condition
CHASSIS DRAWING
|
|
|
|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
